API 6A | 15K PSI | Wear Resistant

Flow Iron: The High-Pressure Arteries of Every Frac Job

Flow iron —the straight pipes, elbows, tees, swivel joints and plug valves that carry high-pressure slurry from the frac pumps to the wellhead. It looks simple, but it's where failures happen. A single failed joint at 10,000 psi can stop the job, damage equipment, and endanger the crew. That's why flow iron is rated to API 6A, why wear sleeves matter in proppant service, and why the quality of your iron is just as important as the quality of your pumps. We supply complete flow iron packages designed for the pressure and proppant load of your specific operation.

High pressure flow iron manifold on frac location

The Components of a Frac Iron System

Flow iron comes in standard shapes that fit together like large, very high-pressure Legos:

Straight Pipe (Missile)

The main horizontal "missile" that collects flow from all the pumps. Usually 3" or 4" nominal, rated to 10,000 or 15,000 psi. Multiple lengths bolted together with hammer unions.

Elbows & Tees

90-degree elbows and tees for routing the flow iron around the location. Elbows are the most wear-prone parts —the slurry slams into the outside wall as it turns.

Swivel Joints

Articulating joints that allow the iron to move with pump vibration and thermal expansion. Critical for preventing stress cracks. Typically used at pump connections.

Plug Valves

Quarter-turn valves for isolating individual pumps or sections of the manifold. Rated to the same pressure as the pipe. Used to shut down a pump without stopping the whole stage.

Why Wear Sleeves Matter

When you're pumping sand at 8 barrels a minute through 3" pipe, the sand particles are doing constant damage to the inside wall. That's where wear sleeves come in:

  • What a wear sleeve is: A replaceable liner inside the pipe. When the sleeve wears thin, you replace just the sleeve —not the whole expensive pipe. It's like changing a brake pad instead of replacing the whole brake rotor.
  • Where wear is worst: Elbows (the slurry slams into the outside wall), tees (flow splits), and any sudden change in direction or diameter. Straight pipe wears the least; elbows and tees wear the most.
  • Material choices: Standard wear sleeves are hardened alloy steel. For very high sand concentrations or long stages, you can specify tungsten carbide coating or ceramic-lined sleeves —more expensive but last 3-5x longer.
  • Inspection schedule: Flow iron should be inspected after every 50-100 stages (or every month, whichever comes first). Wall thickness measurements at elbows and tees. Replace when wall loss reaches 20% of original thickness.

Typical Flow Iron Specifications

Parameter Standard (10K) Heavy Duty (15K)
Pressure rating 70 MPa (10,000 psi) 105 MPa (15,000 psi)
Nominal size 2" - 3" 3" - 4"
Material AISI 4130 / 4140 alloy steel AISI 4145H / 4340 alloy steel
Connection type Hammer union (1502 / 207) Hammer union (1502 / 207)
Wear sleeve Hardened steel, replaceable Hardened steel + optional WC coating
Standard API 6A, PSL 2 API 6A, PSL 3

Frequently Asked Questions

How do I know when flow iron needs to be replaced?

The most reliable method is ultrasonic wall thickness testing. Mark each joint with a number, measure the wall thickness at the thinnest point (usually the outside of elbows and the through-flow of tees), and compare to new wall thickness. When wall loss reaches 20% of the original, replace the joint. You can also visually inspect for signs: dents, cracks, corrosion, or weeping at the connections. Never run iron that shows signs of internal pitting or through-wall wear —at 10,000 psi, a failed joint is a serious safety event.

Can I use flow iron from different manufacturers together?

Technically yes —all standard flow iron uses hammer union connections (1502 or 207 series) that are interchangeable. But there are practical considerations: different manufacturers may have slightly different wall thicknesses, wear sleeve designs and material grades. For critical operations (high pressure, high sand), it's best to use one brand consistently so you know the wear pattern. Also, replacement parts (wear sleeves, seals) may not be interchangeable between brands. Mixing iron is common for spares, but for the main manifold, stick to one supplier.

What's the difference between 10K and 15K flow iron?

10K iron is rated to 10,000 psi (70 MPa). 15K iron is rated to 15,000 psi (105 MPa). 15K iron uses heavier wall pipe, stronger connections and higher-grade material. It costs more but is necessary for deep wells, high-pressure formations or HPHT operations. If your job stays below 8,000 psi surface pressure, 10K is fine and cheaper. If you're regularly at 9,000+ psi surface pressure, you need 15K iron. Always size the iron for your maximum expected surface pressure, not your average —peaks happen.

Need Flow Iron for Your Frac Operation?

Tell us your required pressure rating (10K or 15K), number of pump connections, and typical proppant concentration. We'll supply a complete flow iron package with wear sleeves and spare parts.
