Storage Tanks
Chemical storage tanks hold the additives. Available in various sizes (100-5000 liters) and materials (polyethylene, stainless steel, fiberglass). Tanks include level indicators and venting.
A chemical additive system provides precise, controlled injection of chemicals into well fluids, cement slurry or fracturing fluid. It includes storage tanks, metering pumps, control systems and safety equipment. Used across the oilfield for everything from cementing additives to production chemical dosing.
Chemical additive systems are used across the oilfield:
Chemical storage tanks hold the additives. Available in various sizes (100-5000 liters) and materials (polyethylene, stainless steel, fiberglass). Tanks include level indicators and venting.
Precision metering pumps inject chemicals at a controlled rate. Diaphragm, plunger or peristaltic pumps depending on the chemical and flow requirement. Flow rate is adjustable and repeatable.
Control panel for pump operation. Includes start/stop, flow rate adjustment, and optionally, automation interface (4-20mA, Modbus, etc.). Some systems include batch control or ratio control.
Pulsation dampeners, pressure relief valves, calibration columns, suction strainers, and injection quills. Complete skid package ready for installation and operation.
| Parameter | Typical Range |
|---|---|
| Pump type | Diaphragm / plunger / peristaltic metering pump |
| Flow rate | 0.5 - 500 liters/hour |
| Pressure rating | 10 - 100 bar (145 - 1450 psi) |
| Tank capacity | 100 - 5000 liters per chemical |
| Number of chemicals | 1 - 8 (multi-pump skid) |
| Mounting | Skid mounted, trailer mounted, or containerized |
Single-pump chemical additive skid for one chemical. Compact, simple, easy to operate.
Multi-pump skid for 2-8 chemicals. Centralized control, compact footprint. For complex operations.
Fully custom chemical injection system designed to your specific requirements and fluid types.
Modern metering pumps achieve +/- 1% accuracy under stable conditions. This means if you set the pump to inject 10 liters per hour, the actual flow will be between 9.9 and 10.1 liters per hour. Accuracy depends on pump type, chemical properties, and system pressure conditions. For critical applications, we recommend installing a flow meter on the discharge line for continuous verification.
The system can handle most oilfield chemicals: cement additives, frac additives, production chemicals, water treatment chemicals, acids, solvents and biocides. The wetted parts (pump head, piping, tanks) are selected based on the chemical compatibility. We offer various materials: stainless steel, PVC, PVDF, PTFE-lined, etc. Tell us which chemicals you're using, and we'll select the right materials.
Yes. Our chemical additive systems can be integrated with plant control systems (SCADA, DCS) via 4-20mA signals, Modbus RTU/TCP, or Profibus. The system can be controlled remotely, and flow rates can be adjusted automatically based on process parameters. This is common in unmanned production facilities or remote well sites. We can also provide batch control for specific dosing recipes.
Tell us your chemicals, required flow rates and integration needs. Our engineering team will recommend the right system and provide a quote within 48 hours.
