Choke & Kill | Well Control | 2K to 15K psi

API 16C Pressure Control Equipment: Choke & Kill Systems for Well Control

API Specification 16C (Spec 16C) covers the equipment that controls well pressure during well control operations: choke manifolds, kill manifolds, high-pressure hoses, and rotary heads. This is the "plumbing" of well control —the system that connects the blowout preventer (BOP) to the mud pumps and the flare line. If the BOP is the "brake," the choke and kill manifold is the "steering wheel" —it lets you control pressure while circulating out a kick. API 16C ensures these critical pressure control components are designed, manufactured, and tested to consistent standards. We design and manufacture API 16C-certified choke and kill manifolds, high-pressure fluid control equipment, and associated components —built to the standard, pressure-tested, and supplied with complete certification documentation.

API 16C vs API 6A: What's the Difference?

Factor API 16C API 6A
Scope Choke & kill manifolds, high-pressure hoses, rotary heads Wellheads, Christmas trees, valves, flanges
Purpose Well control during drilling/workover Production wellhead equipment
Pressure Ratings 2,000 to 15,000 psi 2,000 to 15,000 psi
Operating Environment Drilling rig, BOP stack, well control Wellhead, production, permanent installation
Key Components Choke valves, kill valves, flexible hoses, actuators Casing heads, tubing heads, production valves, chokes

API 16C Equipment We Manufacture

Choke Manifold

The pressure-control manifold used during well control. Adjustable choke valves regulate backpressure while circulating out a kick. Manual or hydraulic operation. API 16C certified.

Kill Manifold

The high-pressure pumping manifold used to pump kill mud into the well. Connects the mud pumps to the BOP. High-pressure valves and piping rated for full well pressure.

High-Pressure Hoses

Flexible high-pressure hoses connecting the rig surface equipment to the BOP or wellhead. API 16C certified, reinforced for high-pressure service.

Rotary Head

Rotating control head used for underbalanced drilling and managed pressure drilling. Seals around the drill string while allowing rotation. Part of the API 16C scope.

Frequently Asked Questions

Do we need API 16C certification for our choke and kill manifold?

If you're operating under a drilling contract or regulatory requirements, yes. Most operators and regulatory bodies require API 16C certification for well control equipment. Even where not strictly required, API 16C certification ensures the equipment meets recognized design, testing, and manufacturing standards. We provide complete API 16C certification documentation with every manifold we supply.

What pressure rating should our choke and kill manifold have?

It should match (or exceed) the BOP stack rating. If your BOP is rated for 10,000 psi, your choke and kill manifold should also be rated for 10,000 psi. Common ratings are 3,000 psi (shallow wells), 5,000 psi (standard), 10,000 psi (deep wells), and 15,000 psi (HPHT). Tell us your BOP rating and well conditions, and we'll specify the right manifold pressure rating.

Can you provide complete well control packages, not just manifolds?

Yes. We provide complete well control packages: BOPs (API 16A), choke and kill manifolds (API 16C), wellhead equipment (API 6A), and associated control systems. This gives you a fully integrated well control system from one supplier —designed to work together, tested together, and supported by one manufacturer.

Need API 16C Choke & Kill Equipment?

Tell us your BOP stack rating, well pressure, and control requirements. We'll design and manufacture API 16C-certified choke and kill manifolds and associated equipment —built to the standard, tested, and ready for well control service.
